5 person outdoor hot tub · BG-8833
Retreat 5
A spacious five-person layout with two dedicated loungers.
Base product price$3,799
Base product price. Shipping, applicable taxes, site preparation and installation are quoted separately based on your ZIP code.
Seats52 loungers + 3 seats
Massage39 total jets29 hydrotherapy jets + 10 air jets
Water capacity423 gal1600 L
Footprint94.5 × 86.6 × 37.4 in2400 × 2200 × 950 mm
Standard configuration
What comes with Retreat 5.
Final component brands, colors, electrical requirements and order specifications are confirmed in writing before production.
- Overall dimensions
- 94.5 × 86.6 × 37.4 in (2400 × 2200 × 950 mm)
- Internal dimensions
- 2000 × 1850 × 800 mm
- Water capacity
- 423 gal (1600 L)
- Dry weight
- 661 lb (300 kg)
- Massage system
- 2 × 2 HP massage pumps; 1 × 0.5 HP circulation pump
- Air blower
- 1 × 1 HP
- Heating
- 3 kW heater
- Filtration
- Paper filter, circulation pump and ozonizer
- Lighting
- 5-inch underwater LED and 12 waterline lights
- Comfort
- 3 PU pillows
- Shell / frame
- USA Aristech acrylic / hot-dip galvanized steel
- Electrical
- 220–240 V, 50/60 Hz; final US-site requirements must be confirmed by a licensed electrician
